21
X-Series Waterblast Unit
Jetstream 5200
Bareshaft Pump Installation
Guidelines
All of the previous requirements for the 4200
are the same for 5200 except as noted below:
5200 series 400 hp max 518 rpm max
Water Supply
The 5200 pump cannot be gravity fed and re-
quires 40-50 psi suction water pressure at full
pump speed to operate. As such, it is supplied
with lube water ow control valves mounted
on a manifold in the rod box area. All uid
ends have a maximum inlet supply pressure
of 75 psi.****
Rod Box
The 5200 pump is supplied with a keyed
locking rod box that is enclosed from the ele-
ments.
Side Bypass
The 5200 pump has been developed in con-
junction with a side mounted bypass to re-
duce clutter on the top of the Fluid End and to
provide a means of attaching accessories to
the bypass without ow restrictions such as a
hydrothrottle.
