User and Installaon Manual
Compact MPA
3.3 MPA 1603 GA ALARM PANEL
Outer dimensions: 144 x 96 mm.
Operang voltage: 24VDC supplied from the MPA1600 Operaon Unit.
Current drain maximum: 100 mA.
Ingress Protecon (IP): 44
Compass safe distance (standard): 60 cm
Compass safe distance (steering): 40 cm
3.4 AMPLIFIER 1671
Electrical:
Power output (THD 1%) 250W (RMS)
Max load: 40 ohm
Frequency Response (+1/-3.5dB) 300Hz to 7KHz
THD at 1 KHz, Rated Output Less than 1%
HPF -3dB at 150Hz
Signal to Noise Rao Beer than 80dB
Input Sensivity/Impedance 0.775V/47K ohm Balanced
General:
Power source (primary) AC 230V (220/240) or
(primary alternave) AC 115V (110/120) 50Hz/60Hz
(backup) DC 24V
Maximum current drain AC (110V) 5A
Dimensions W:483 x H:44 x D:320 mm
Weight 5.5 Kg.
3.5 CABINETS
Type: Jotron Compact cabinet 19” 5x1U
Dimensions W:585 x H:618 x D:470 mm
Weight 30 kg.
Ingress Protecon (IP) 22
