User and Installaon Manual

Compact MPA

9.12 MPA 1643 - MECHANICAL LAYOUT

9.13 MPA 1643 - EXTERNAL CONNECTION

  

Audio + 1 7

Audio - 2 8

RS485- 3 9

RS485+ 4 10

+24VDC 5 11

0V 6 12

 TB2

24VDC 1

0V 2

0V I.S rail
