jotron MPA 1603 GA - Phontech 1671 - Mechanical Layout; Phontech 1671 - External Connection

61
User and Installaon Manual
Compact MPA
9.14 PHONTECH 1671 - MECHANICAL LAYOUT
9.15 PHONTECH 1671 - EXTERNAL CONNECTION
Audio output
1 Standby In_1/OutputB_1
Standby amplier input
2 Standby In_2/OutputB_2
3 OutputA_1
Amplier output
4 OutputA_2
5 Chassis_GND
