Chapter 2 INSTALLATION OF THE SCANNER
2.1 SELECTING THE INSTALLATION POSITION
2-6
Others
The design of the mounting platform for the scanner should take into account the
vibration requirements defined by IEC 60945.
Vibration
Frequency
2 to 13.2 Hz
13.2 Hz to 100 Hz
Amplitude
+/-1 mm +/-10 %
Acceleration
7m/s
2
constant
All installations should facilitate protection of equipment, including cabling, from
damage.
The cables should be kept as short as possible to minimize attenuation of the signal.
Crossing of cables should be done at right angles(90°) to minimize magnetic field
coupling.
Install the radar cable as far as from the cables of other radio equipment in order to
prevent other radio equipment from interfering with the radar operations. Especially
inter-wiring cables between scanner unit and display unit of the radar should not be
run parallel with the cables of other radio equipment.
Cable should not be exposed sharp bends.
Ensure that the equipment is grounded.
After installation
After you have completed the installation work, make a installation report with your
signature and explain it to the customer.
Then request him to keep the report on board a ship.
The installation report is now available for download on the our Marine Service
Department website (https://www2.msd.jp/).
