Chapter 4 ADJUST MENU SETTINGS

4.13 DISPLAY SCREEN

4-87

NSTALLATION MANUAL

4.13 DISPLAY SCREEN

Sets the display screen.

 "Display Screen" operations

1 Open Display Screen from the Adjust Menu.

"Display Screen" menu appears.

4.13.1 OWN VECTOR WIDTH

Sets the own vector width.

 Setting Own Vector Width

1 Open Display Screen - Own Vector Width .

"Own Vector Width" menu appears.

Press the cursor key or turn the [MULTI] control to set the own vector width.

The own vector width can be set between 0 and 5.

4.13.2 OWN OUTLINE

Sets the own outline.

Reference:

Length, width, position the radar antenna, GPS antenna position of the own ship should be

measured beforehand.
