Chapter 4 ADJUST MENU SETTINGS
4.6 SCANNER
4-21
4
NSTALLATION MANUAL
4.6.2 PRF FINE TUNING
Adjusts PRF fine tuning.
Reference:
This setting cannot be performed simultaneously with the setting of "4.6.3 STAGGER
TRIGGER".
Adjusting PRF Fine Tuning
1 Open Scanner - PRF Fine Tuning .
"PRF Fine Tuning" menu appears.
Press the cursor key or turn the [MULTI] control to set the PRF Fine Tuning.
Fine-tune the transmitting repetition frequency of the transmitter in the range 90 to
100%.
If radar's interference patterns are concentrically displayed, increment or decrement
the set value by 3 to 4 in order to heighten the effect of interference rejection.
The same operation can be performed by pressing the [TX/PRF] key several times.
One of 32 levels 0-31 can be set.
