Chapter 4 ADJUST MENU SETTINGS
4.11 MAINTENANCE
4-78
4.11.5 INTERNAL SETTING
The system can save internal memory data such as item settings in menus via USB. If the
processing circuit in the system has been replaced, the set values before the circuit
replacement can be restored by reading the set values you saved before the replacement.
To save the internal memory data, the USB memory must be inserted into "USB
MEMORY" on the control panel beforehand.
"Internal Setting" operations
1 Open Maintenance - Internal Setting .
"Internal Setting" menu appears.
Internal Memory to USB
Saves the internal memory data, such as item settings in menus, via USB.
The internal memory data should be saved at completion of system setting, and the
operation condition should be saved periodically.
1 Open Internal Setting - Internal Memory to USB .
"Internal Memory to USB" menu appears.
Select the items, then save the internal memory data via USB.
Items which can be saved via USB
RADAR Echo: Outputs the RADAR Echo settings in the Main Menu and the
Adjust Menu via USB.
Function Setting: Outputs the Function Setting via USB.
Basic Adjustment: Outputs the Basic Adjustment settings in the Adjust Menu via
USB.
Main Menu: Outputs the settings of the Main Menu and the soft key menu
and radar screen settings via USB (except RADAR Echo and
Function Setting).
