Radar Failure Check List
When placing an order for repair of the product, it is requested that you could confirm the check
items and fill the results and sent the sheet to our contact.
If there is any unclear items, contact the ship on which the product is installed, and give the
correct information on the product.
Ship name:
Phone: Fax:
Radar general model name: JMA-
Serial No. :
(Write the full model name correctly)
(1) Check the following items in the order of the number, and circle the applicable answer
between YES or NO. If the item cannot be determined as YES or NO, explain in detail in
the item (18), others.
(2) If any of the items (1) to (5) is marked as NO, check the fuse of the NDC-1486.
(3) Check the items (4) to (15) while the transmission (TX) is ON.
* Functions mentioned in the items (14), and (15) may be optional, answer is not necessary.
No. Check Item Result
(1) Power can be turned on. (The lamp on the operation panel is lit) YES NO
(2)
A few minutes after powering-on, it will become standby status (TX
Ready).
YES NO
(3)
When powering-on (or TX ON), LCD displays something (LCD is
lit).
YES NO
(4)
The scanner rotates at the transmission (TX) ON.
(Check the following items while transmission is ON)
YES NO
(5)
Current is supplied to the magnetron. (Refer to the instruction
manual)
YES NO
(6) Turning is enabled. (Check with the range of 8 km or more) YES NO
(7) Fixed marker is displayed. YES NO
(8) VRM is displayed. YES NO
(9)
While noise is displayed while set at STC and FTC minimum, GAIN
maximum, IR-OFF and range 32km.
YES NO
(10) Target reflection echo is displayed. YES NO
(11) Sensitivity of reflection echo is normal. YES NO
(12) EBL is displayed. YES NO
(13) Cursor mark moves. YES NO
*(14) GYRO course can be set and normally displayed. YES NO
*(15) LOG speed can be normally displayed. YES NO
(16) Others (Error message, etc. )
To Next Page
