1-16
NCE-5163-F
Operation Unit
JMA-900B Displau Unit
NDC-1445 Processin
g
Uni
t
NWZ-170-E Monitor Unit
(23.1 inch LCD Monitor)
CQD-2130
Option Terminal Board
YCBD-1832
Filter Unit
The bottom side of Processing Unit
CQD-2128
Radar Tarminal Board
