4-11
S2 設定表／S2 SETTING TABLE
1 2 3 4 5 6 7 8
ON
BSHLOG ALARM
OFF
ON
GYRO SIMULATOR
OFF
ON
LOG SIMULATOR
OFF
N.C. N.C.
5 SEC ON
GYRO ALARM
TIME
0.2 SEC OFF
NMEA(HDT/THS) ON
HEADING SENSOR
SOURCE
GYRO SIGNAL OFF
4800 bps OFF OFF
9600 bps ON OFF
19200 bps OFF ON
OTHER SETTING
NMEA BAUDRATE SETTING
38400 bps ON ON
Table 4-2 OTHER SETTING switch（S2 DIP）
