JUKI IP-420 - 4-4. Threading the machine head

– 20 –
4-4. Threading the machine head
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start or
the sewing machine.
4-5. Installing and removing the bobbin case
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start or
the sewing machine.
In addition, be sure to close the hook cover when re-starting the sewing machine so as to prevent
personal injury or death.
1) Open hook cover
1
.
2) Raise latch
3
of bobbin case
2
, and remove
the bobbin case.
3) When entering bobbin case, insert it with the
latch tilted until "click" sounds.
If it is not fully inserted, bobbin case
2
may slip off during sewing.
1
3
2
AMS-210ENSS
AMS-210ENSL
AMS-210ENHS
AMS-210ENHL
