JUKI IP-420 - Configuration

– 2 –
Air regulator
(for pneumatic type only)
2. CONFIGURATION
1
Machine head
2
Wiper switch
3
Temporary stop switch
4
Feeding frame
5
Intermediate presser
6
Thread stand
7
Operation panel (IP-420)
8
Power switch
9
Control box
!0
Foot pedal
!1
Manual pedal (Excluding pneumatic type)
1
2
3
4
6
7
8
9
!0
5
!1
