– 74 –
Button and display Description
M
SEWING SHAPE display The sewing shape of the currently selected pattern is displayed
N
NUMBER OF STITCHES
display
The number of stitches for the currently selected pattern is displayed.
O
X ACTUAL SIZE VALUE
display
The actual X size value of the sewing shape which is being selected is displayed.
When an actual value input is selected, the X ACTUAL VALUE SETTING button
is displayed according to the setting of MEMORY switch .
/
Refer to
“
@
-2-6. Changing item data” p.40
.
P
Y ACTUAL SIZE VALUE
display
The actual Y size value of the sewing shape which is being selected is displayed.
When an actual value input is selected, the Y ACTUAL VALUE SETTING button
is displayed according to the setting of MEMORY switch .
/
Refer to
“
@
-2-6. Changing item data” p.40
.
Q
EDIT DATA display The data which is being edited on the currently selected edit item is displayed.
* When no edit item is selected, this display is not given.
A
MEDIA PATTERN WRITE
button
Data on a media pattern is written.
When this button is pressed, the new media pattern registration screen is
displayed.
* This button is displayed when the media pattern is selected.
B
USER’S PATTERN WRITE
button
Data on a user’s pattern is written.
When this button is pressed, the new user’s pattern registration screen is
displayed.
* This button is displayed when the media pattern is selected.
C
SEWING DATA TYPE
display
The type of data read from a medium is displayed.
: Vector form data
: M3 data
: Standard format of sewing
* This display is given when the media pattern is selected.
A
TRAVEL AMOUNT IN X
DIRECTION display
The amount of travel in the X direction which is registered to the pattern button
No. being selected is displayed.
* This display is given when a direct pattern is selected.
B
TRAVEL AMOUNT IN Y
DIRECTION display
The amount of travel in the Y direction which is registered to the pattern button
No. being selected is displayed.
* This display is given when a direct pattern is selected.
