JVC GY-DV700W User Manual

E-27
2. CONTROLS, INDICATORS AND CONNECTORS
E-26
2. CONTROLS, INDICATORS AND CONNECTORS
Shows the input level of the audio input channel.
Display ON/OFF can be selected using the VF DISPLAY menu screen.
☞ See "AUDIO DISPLAY" on page 72.
VCR in standby mode
VCR in save mode
VCR in stop mode
VCR in record mode
VCR in fast-forward mode
VCR in rewind mode
VCR in reverse search mode
Remaining tape indication (displayed in 1-minute steps)
When the tape is used for a long time, the remaining tape may not be
indicated accurately. At the beginning of the tape, in particular, the indication
may show smaller value than the actual one.
Time code display
Time code display is available when the "REC TIME" item on the VF DISPLAY
menu screen is set to TIME CODE.
☞ See "REC TIME" on page 72.
Voltage indication (displayed in 0.1 V steps)
Shows the F-number of the connected lens.
It is not displayed when the lens is removed. For some lenses, no display
appears.
Display ON/OFF can be selected on the VF DISPLAY menu screen.
☞ See "F NO.DISPLAY" on page 72.
In the Super Scene Finder (S.S.F.) mode, the number of memorized scenes
is shown.
M: In MARK mode
C : In CUE mode
Number: Number of memorized scenes
2-9 Indications in Viewfinder (Cont'd)
● Status 1
In addition to the information on the Status 0 screen, this screen displays audio indicators and information on remaining tape,
voltage and lens F-number.
Indication Indication Contents
SCENE FILE A, B, OFF
WHITE BAL A, B, PRESET, FAW
FILTER 3.2K, 5.6K+1/8ND, 5.6K, 5.6K+1/64ND
SHUTTER OFF, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/50.1 to 1/2053.6 (in VARIABLE mode),
EEI (in ALC mode)
GAIN -3dB, 0dB, 6dB, 9dB, 12dB, 18dB, LOLUX, ALC
IRIS LEVEL NORMAL, BACK L, SPOT L
FULL AUTO ON, OFF
REC TIME Remaining tape time or time code.
● Status 2
This screen displays the camera setup statuses.
Event display is not available while this screen is displayed.
8
(Example)
CH1- - - - + - -
CH2- - - - + - -
9
STBY
SAVE
STOP
REC
FF
REW
EJECT
0
(Example)
< 60
(Example)
12: 34: 56: 20
A
(Example)
12.4V
B
OPEN, F2, F2.8, F4,
F5.6, F8, F11, F16,
CLOSE
C
(Example)
M: 099
Display position
Function
Display
● Status 0
2-9 Indications in Viewfinder (Cont'd)
1
7
2
3
4
5
6
C
8
7
9
0AB
1
2
3
4
5
6
SCENE F I LE
WH I T E B A L A
A
FILTER
SHUTTER 1/10
3.2K
00
GA I N 6 d B
I R I S LEVE L NORMAL
I R I S DE T EC T NORMA L
FUL L AUTO OFF
REC T I ME < 6 0
ACCU- FOCUS
G
F
I
B
SD
ACCU - FOCUS
G
F
I
F5.6
STBY 4V21.<60
B
CH1 ----+--
CH2 ----+--
SD
M909
Status 0
Status 1 Status 2
Display Position Display Function
1
ACCU-FOCUS Blinks during the ACCU-FOCUS operation.
SKIN AREA Blinks while the skin tone detail color area is displayed.
S Displayed when the SHUTTER or V-SCAN is ON.
FAS Displayed when the Full Auto Shooting is ON.
ALC Displayed when the ALC alone is ON.
2
G Displayed in other modes than 0 dB, LOLUX and ALC.
L Displayed during LOLUX operation.
3
F Displayed when FAW alone is ON.
4
I Displayed when IRIS BACK LIGHT or IRIS SPOT LIGHT is selected.
5
SD Displayed while the Skin Detail function is in operation.
6
B Displayed when BLACK STRETCH or BLACK COMPRESSION is selected.
7
Event display See the table below.
Switch Event Display Contents
ZEBRA ZEBRA ON, OFF
BLACK BLACK STRETCH, NORMAL, COMPRESS
GAIN GAIN –3 dB, 0 dB, 6 dB, 9 dB, 12 dB, 18 dB, ALC
WHT. BAL WHITE BAL A, B, PRESET, FAW
FULL AUTO FULL AUTO ON, OFF
AUTO IRIS IRIS BACK L, NORMAL, SPOT L, BACK L, SPOT L
LOLUX LOLUX ON, OFF
FILTER knob FILTER 3.2K, 5.6K+1/8ND, 5.6K, 5.6K+1/64ND
VTR VTR STBY, SAVE
AUTO KNEE AUTO KNEE ON, OFF
7 Event display
Event is displayed in the viewfinder for only about 2 seconds when any of the following switches is operated.
When the RS-232C cable
is connected, the VCR
operation mode may not
be displayed correctly.
Note:
