JVC GY-DV700W User Manual

E-91
14. OTHERS
E-90
14. OTHERS
• Is the SERVO indicator or “SYNC INH” displayed on the counter display?
If so, check the input sync signal.
• The front section's recording level control cannot be used to change the recording
level of the sound input to CH2. Use the side section's CH2 recording level control
for this purpose.
14-1 Troubleshooting (Cont'd)
TROUBLES WITHOUT ERROR CODE OUTPUTS
Symptoms
Remedy
Power cannot be switched ON.
• Is power supply connected properly?
• Is battery pack recharged?
• When the lithium battery is depleted, it may not be possible to turn on the power.
• Was the power turned ON immediately after being turned OFF?
Wait at least 5 seconds before turning the power ON again once it has been turned
OFF.
Operation buttons on the GY-DV700W
don't work.
• Check whether the VCR Setup Menu item No. 050 REMOTE SELECT has been set
to "IEEE1394" or "RS232C". If so, change the setting to "LOCAL".
• Is the cassette cover open?
The GY-DV700W remains inoperative as long as the cassette door is open.
Recording is not possible.
• Is switch on cassette set to REC? If it is set to SAVE, set it to REC.
Noise interferes with playback video.
• Video head may be clogged with dirt. Clean head with the special head cleaning
tape. (See page 7 and the separate sheet "Precautions for Use of Head Cleaning
Tape".)
Time code data is not shown as on-
screen-display.
• Time code data is not shown as on-screen-display during recording or playback.
The data is shown only on the counter display.
Time code and user's bit data are not
shown on the counter display.
• Is the COUNTER switch set to "CTL"? If so, set the switch to "TC" or "UB".
Remaining battery power display is
incorrect.
• The VCR Setup Menu item No. 396 BATTERY TYPE may not be set correctly in
accordance with the type of battery in use. If the menu item setting is incorrect, set
it correctly using the VCR setup menu item BATTERY TYPE.
• Is the battery old?
Battery alarm is displayed and the GY-
DV700W enters the non-operating mode
even when a fully charged battery is used.
Cassette cannot be ejected after the
power is turned ON.
• The capacity of the power supply may be insufficient. Check the power voltage.
Viewfinder image looks dark or unclear.
• Adjust the viewfinder's contrast and bright controls.
• Is the filter turret set to 5600K+ND?
• Is the iris closed?
• Is the shutter speed too fast?
• Is the viewfinder cable correctly connected?
Noise appears when playing back a tape
recorded on another unit.
• When a tape recorded on another unit is played back or used for recording, this
phenomenon may occur due to tracking errors.
The transient section between scenes
recorded on other units and those
recorded on this unit may appear
disturbed.
The front section's recording level control
doesn't work.
• Is the VCR Setup Menu item No. 246 FRONT VOLUME ENABLE set to "DISABLE".
If so, set to "ENABLE".
The front section's recording level control
doesn't change the recording level of the
sound input to CH2.
Sound and picture are disturbed during
playback.
• Is the sync signal input to the SYNC IN connector disturbed? If so, check and
remedy the input sync signal.
Recording operation stopped.
TROUBLES WITH ERROR CODE OUTPUTS
14-1 Troubleshooting (Cont'd)
4200
Operation stops. All operations
are rejected.
Error Code
Error Details GY-DV700W Operation Remedy
3200 Tape loading impossible. Operation stops. All operations
are rejected.
Switch the power OFF and then
switch it back ON. However, the tape
may be damaged depending on the
situation. Please consult the person
in charge of professional video
equipment at your nearest JVC-
authorized service agent.
3300 Tape unloading impossible.
5606 to 5607 Tape is slack. Operation stops. All operations
are rejected.
Switch the power OFF and then
switch it back ON. However, the tape
may be damaged depending on the
situation. Please consult the person
in charge of professional video
equipment at your nearest JVC-
authorized service agent.
5702 Tape end sensor error. Operation stops. All operations
are rejected.
5802 Tape beginning sensor error. Operation stops. All operations
are rejected.
7001 Drum rotation stopped. Operation stops. All operations
are rejected.
7101 Capstan rotation stopped. Operation stops. All operations
are rejected.
7202 to 7203 Supply reel rotation error. Operation stops. All operations
are rejected.
7302 to 7303 Take up reel rotation error. Operation stops. All operations
are rejected.
7305 Irregular tape winding when
unloading.
4100 Irregular eject operation. Operation stops. All operations
are rejected.
Cassette housing abnormality. Operation stops. All operations
are rejected.
Operation stops. All operations
are rejected.
5605 Tape is cut. Operation stops. All operations
are rejected.
Open the cassette cover by using the
EJECT switch and then switch the
power ON again.
For servicing
See the service manual page 1-26, “1.18 WARNING CODES”.
→
