Kaco blueplanet 3.0 TL3 M2 WM OD IIG0 Operating Instructions

KACO
blue-
planet
3.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
4.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
5.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
6.5 TL3
M2 WM
OD IIG0
KACO
blue-
planet
7.5 TL3
M2 WM
OD IIG0
KACO
blue-
planet
8.6 TL3
M2 WM
OD IIG0 -
3TL301
KACO
blue-
planet
9.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
10.0 TL3
M2 WM
OD IIG0 -
3TL301
Rated current
3x 4.20 A
[@415V];
3x 4.35 A
[@400V];
3x 4.60 A
[@380V]
3x 5.60 A
[@415V];
3x 5.80 A
[@400V];
3x 6.10 A
[@380V]
3x 7.00 A
[@415V];
3x 7.25 A
[@400V];
3x 7.60 A
[@380V]
3x 9.10 A
[@415V];
3x 9.50 A
[@400V];
3x 9.90 A
[@380V]
3x 10.50
A
[@415V];
3x 10.90
A
[@400V];
3x 11.40
A
[@380V]
3x 12.00
A
[@415V];
3x 12.50
A
[@400V];
3x 13.10
A
[@380V]
3 x 12.60
A
[@415V];
3 x 13.00
A
[@400V];
3 x 13.70
A
[@380V]
3x 14.95
A
[@415V];
3x 14.50
A
[@400V];
3x 15.20
A
[@380V]
Max. continuous current 3 x 4.8 A 3 x 6.4 A 3 x 8.0 A 3 x 10.5 A 3 x 12.0 A 3 x 13.2 A 3 x 14.0 A 3 x 15.5 A
Contribution to peak short-circuit
current ip
34.96 A 35 A 41 A 35 A 41 A
Initial short-circuit alternating
current (Ik" first single period ef-
fective value)
16.5 A 18.9 A 16.5 A 18.9 A
Short circuit current continuous
[ms] (max output fault current)
1,3 A
Inrush current 1.033 A [RMS (20ms)]
Rated frequency 50/60 Hz
Frequency range 45 - 65 Hz
Reactive power 0 - 95% Snom
cos phi 1 - 0.3 ind/cap
Number of feed-in phases 3
Distortion factor (THD) 0.36 % 0.32 % 0.31 % 0.29 % 3.85 % 0.27 %
Max. voltage range (up to 100 s) 287.5 V / 500 V
AC overvoltage protection no
4.2 General Data
KACO
blue-
planet
3.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
4.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
5.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
6.5 TL3
M2 WM
OD IIG0
KACO
blue-
planet
7.5 TL3
M2 WM
OD IIG0
KACO
blue-
planet
8.6 TL3
M2 WM
OD IIG0 -
3TL301
KACO
blue-
planet
9.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
10.0 TL3
M2 WM
OD IIG0 -
3TL301
General electrical data
Max. efficiency 98.1 % 98.2 % 98.3 % 98.5 %
European efficiency 96.6 % 97.1 % 97.4 % 97.6 % 97.7 % 97.9 % 98.3 %
Self consumption: Standby 3 W
Feed-in from 20 W
Transformer unit no
Protection class / over voltage
category
III / III
Grid monitoring Country-specific
Distribution system TN-C-System, TN-C-S-System, TN-S-System, TT-System
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 11
EN

Kaco blueplanet 3.0 TL3 M2 WM OD IIG0 Specifications

General

Brand	Kaco
Model	blueplanet 3.0 TL3 M2 WM OD IIG0
Category	Inverter
Language	English
