TECHNICAL DESCRIPTION Kamstrup 162M/382M
5512-1040 GB/05.2012/Rev. C1
31
4.1 Value field
This field is used for displaying register values. The number of register values depends on the meter's
configuration. The value field reading depends on the value stated as well as the meter’s set-up. Meter numbers,
special data etc. are indicated by 8 digits, energy is stated in [6.1], or [7.0] format kWh/kvar, and power in [2.3]
format (00.000) kW/kvar. Date/time is stated according to the format YY:MM:DD and HH:MM:SS.
The value field can be configured to display leading zeroes of energy readings.
4.2 Unit field
The unit field is used for displaying the units of registers in the value field.
4.3 Text field
The text field can be used either for additional information to the unit field regarding values in the value field or
for text information. In the latter case, text messages are shown as sliding letters in the field.
4.4 Mains voltage reading
The mains voltage readings per phase L1, L2 and L3 indicates whether voltage is applied to the individually
phase input terminal or not.
Indications L1, L2, L3 Indicate
On The volta
Table 13: Main voltage indication.
The minimum voltage limit is 160 VAC 5 %. If the voltage remains below minimum limit for more than 1 second
in all phases, the meter is reset and the processor shuts down. Subsequently, the meter carries out a normal
start.
4.5 Phase current indication
The direction of the current for each phase is shown with these indicators. It can be useful when checking of
correct input/output installation.
Indications - + Indicate
On The load is above minimum limit (2.3W).
Table 14: Phase current indication.
The minimum load limit is approx. 10 mA. If the phase current is lower than this value, energy registration stops
and the phase current indication turn off in the display.
