TECHNICAL DESCRIPTION Kamstrup 162M/382M
5512-1040 GB/05.2012/Rev. C1
74
12 Test specifications
Standard test of the meter must be carried out according to the specifications described below. Depending on the
selected configuration such as energy type, class etc., the specification will change.
Test
-
ID
Name Duration
[kWh]/[sec]
Phase
angle [°]
Voltage
[V]
Current
phase 1 [A]
Current
phase 2
[A]
Current
phase 3
[A]
Kamstrup-
MPE [±%]
Standard
MPE [±%]
1 Pre-heat 0 230 100 100 100 - -
2 No-load 0 264.5 0 0 0 1 pulse 1 pulse
3 Pre-heat 0 230 100 100 100 - -
4 Imin 0 230 0.025 0.025 0.025 1 pulse 1 pulse
5 Itr 0 230 0.5 0.5 0.5 2.5 3.5
6 10xItr 0 230 5 5 5 1.5 2.5
7 10xItr cos=0.5 60 230 5 5 5 2 3
8 10xItr Phase 1 0 230 5 0 0 2.5 3.5
9 10xItr Phase 3 0 230 0 0 5 2.5 3.5
10 100% Imax 0 230 100 100 100 1.5 2.5
11 Display 0 230 0 0 0 1.5 1.5
