TECHNICAL DESCRIPTION Kamstrup 162M/382M
5512-1040 GB/05.2012/Rev. C1
46
8 Technical specifications
8.1 Approvals and standards
The meter is type approved according to the Measuring Instrument Directive (MID) for active positive energy and
according to national requirements for other energy sizes.
Type test according to
Active positive energy
Reactive energy and
active negative energy
EN 50470-1 (MID)
IEC 62052-11
EN 50470-3 (MID)
IEC 62053-21
IEC 62053-23
Terminal according to DIN 43857
S0 pulse output according to DIN 43864
Optical reading according to IEC 62056-21 (IEC 61107)
OBIS codes according to IEC 62056-61
Interface classes IEC 62056-62
Data link layer IEC 62056-72
8.2 Technical data
Measuring principle:
- Current: One-phase current measurement by current shunt
- Voltage: One-phase voltage measurement by voltage divider
Nominal voltage Un:
230VAC -20 - +15 %
3x230VAC -20 - +15 % (only applies to Aron meter)
3x230/400VAC -20 - +15 % (does not apply to Kamstrup 1-phase and Aron meter)
Current
I
tr
- I
b
(I
max
):
3-phase without breaker 3-phase with breaker
0,25-5(100
)
A 0,25-5(85
)
A
Class: A, B (active energy)
1, 2 (Reactive nergy)
1-phase without breaker 1-phase with breaker
0,25-5(100
)
A 0,25-5(85
)
A
