TECHNICAL DESCRIPTION
Kamstrup 162M/382M
5512-1040 GB/05.2012/Rev. C1
58
10.2.3
Configuratio
n 3 ( JJ-K-LL-M-NN )
JJ
Disconnect
set-up
K
Peak
power
LL
GMT
M
Available
NN
Unit pulse input
For creation of disconnect configuration (JJ)
, complete the form under
10.7 Display configuration
.
J
J
K
LL
M
NN
JJ
Disconnect set-up
None
00
K Peak power
Peak
p
ower standard
0
Peak
p
ower for tariff 1
1
Peak
p
ower for tariff 2
2
LL GMT
0 GMT London
00
1 DK - D
E - FR - ES
01
2 FI
02
3
03
4
04
5
05
6
06
7
07
8
08
9
09
10
10
11
11
12
12
-11
13
-10
14
-9
15
-8
16
-7
17
-6
18
-5
19
-4
20
-3
21
-2
22
-1
23
M
A
vailable
None
0
NN
Unit
pulse input
None
00
kWh
01
m3
02
L
03
57
59
