Kamstrup 162M - Configuration 2 (FFF-GG-HH-I)

TECHNICAL DESCRIPTION Kamstrup 162M/382M
5512-1040 GB/05.2012/Rev. C1
57
10.2.2 Configuration 2 ( FFF-GG-HH-I )
FFF Display configuration
GG Target date
HH Debiting logger interval
I
Pulse output lenght / alarm input on module port
For creating display configuration (FFF), complete document no. 5811-549 GB, see 10.7 Display configuration. For
information about optional display configurations, please contact Kamstrup A/S.
The below table gives examples of released display readings.
GG Target date GG HH I
Controlled externally 00
1. 01
2. 02
3. 03
: :
: :
: :
27 27
28 28
HH Debiting logger interval
None (controlled externally) 00
Monthly 01
Every second month, January 02
Every second month, February 03
Every third month, January 04
Every third month, February 05
Every third month, March 06
Half-yearly, January 07
Half-yearly, February 08
Half-yearly, March 09
Half-yearly, April 10
Half-yearly, May 11
Half-yearly, June 12
Y
early, January 13
Y
early, February 14
Y
early, March 15
Y
early, April 16
Y
early, May 17
Y
early, June 18
Y
early, July 19
Y
early, August 20
Y
early, Septembe
r
21
Y
early, Octobe
r
22
Y
early, Novembe
r
23
Y
early, Decembe
r
24
I Pulse output lenght / alarm input on module port I
30 msecs. pulse length / no alarm input 1
30 msecs. pulse length / alarm input 2
80 msecs. pulse length / no alarm input 3
80 msecs. pulse length / alarm input 4
