4.6 Tariff indication
The tariff indicator can show T1, T2, T3, T4, T5, T6, T7 and T8 to indicate the currently active tariff. The tariff
reading is updated every 10 sec., i.e. it may take up to 10 seconds from a tariff shift until the current reading is
displayed.
The tariff indication are switched off if a display configuration without tariff reading has been selected.
4.7 Current quadrant reading
The total load is indicated by the arrows for imported active power, exported active power, inductive reactive
power and capacitive reactive power, respectively.
The current quadrant reading is an instantaneous total value for all three phases. The reading is not active when
the load is below the minimum limit of 10 mA RMS.
This reading is On/Off-configurable.
4.8 Breaker status
If the meter is configured with an internal breaker, the position of the breaker is indicated as either connected or
disconnected.
4.9 Object identification field
Field for identification of the value in the value field. Uses OBIS codes in connection with identification.
This reading can be opted out.
The identification field is constructed as CC.DD.E.FF.
CC represents the quadrant in which the registration is made.
DD The physical size.
E Tariffings.
FF Debiting data (historical data).
The most frequently used values are stated in the table below.
CC (energy types) DD (physical sizes) E (tariffings) FF (debiting data)
1 – active + quadrants 1+4 _2 –
