2-5
Illustrated Parts Breakdown
032-0358-EN Rev B
Overhead Assembly Parts List
Item Part No. Description
1 1.006.3077 24V Power Supply
2 0.830.0360 Hook and Loop Fastener
3 #10-32 Nut
4 1.006.3078 2520 Varian Power Supply
5 0.830.0360 Hook and Loop Fastener
6 #10-32 Nut
7 1.007.1007 Limit Switches (set)
8 0.830.2548 Spindle Assembly
9 1.006.5842 Rotation Stepper Motor
10 0.830.0457 Network Switch and Power Cable
11 0.830.0360 Hook and Loop Fastener
12 0.830.1997 Toroid Isolation Transformer
13 SHCS 5/16-18 x 1 Long
14 1.010.0953 Power Bracket Assembly
15 1.007.4094 Buss #HTB-84M
16 1.006.3075 10A Fuse Digi-Key #F985-ND
17 1.006.3074 2.5A Fuse Digi-Key #F979-ND
18 1.006.3076 0.25 A Fuse Digi-Key #F939-ND
19 1.005.8617 10A/115VAC Circuit Breaker
20 1.007.4095 Fuse Label (not shown)
21 1.007.6324 Line Choke
22 1.005.8629 Platform Motor
23 1.007.6644 Ethernet Panel Mount Cable
24 1.005.8632 System Board
25 1.005.8624 Embedded Board
26 1.007.4097 Warning System External Cable Assembly
27 1.007.4098 Door Interlock External Cable Assembly
28 1.007.4099 Control Box External Cable Assembly
29 1.007.4100 Chair External Cable Assembly
30 1.007.4101 Overhead Fan (pair)
