2-3
Illustrated Parts Breakdown
032-0358-EN Rev B
System Assembly Parts List
Item Part No. Description
1 1.007.6265 Wall Stabilizer (not shown)
2 1.006.5157 Upper Cover
3 BHCS #8-32 x 3/8 Long
4 1.013.0489 Resident Indicator Panel
5 1.011.1964 Receptor Assembly
6 1.013.1578 Chair Assembly
7 1.011.4086 Leveler - 3/8-16 LG HX BC 1000# Cap
8 0.830.0200 Leveler - 3/8-16 LG BC 1000# Cap
9 1.011.4014 Leveler - 3/8-16 LG HX SL1000# Cap
10 0.830.5669 Lower Plate Weldment
11 1.011.1954 X-Ray Source Assembly
12 1.007.4085 Laser Line Assembly
13 1.013.0173 Lower Cover Assembly
To Next Page
