KaVo OP 3D Vision User Manual

2-13
Illustrated Parts Breakdown
032-0358-EN Rev B
Chair Assembly Parts List
Item Part No. Description
1
1.007.4118
Chair Receptacle Plate Assembly
2
1.006.6066
Patient Alignment Board
3
1.007.4119
Patient E-Stop External Cable
4
1.007.4121
Chair Junction Cable
5 SHCS 1/4-20 x 5/8 Long
6 1/4 Split Washer
7
1.007.4122
Rail
8
0.830.2024
Slider Plate
9
1.007.4125
Wheel
10
1.007.4126
Wheel Axle
11
1.007.4127
Actuator Plate
12
1.007.4128
Receptacle Flange
13
1.013.1577
Assembly, Seat Bottom
14
1.013.1576
Pad, Seat Bottom
15
1.007.6283
Seat Frame
16
0.830.0362
Plastic Spacers
17 M6 Split Washer
18 SHCS M6 x 45mm Long PHP ZN
19
1.013.1579
Seat Pad, Back
20
1.011.8381
Bracket, Chair Mounting
