KaVo OP 3D Vision User Manual

2-7
Illustrated Parts Breakdown
032-0358-EN Rev B
Rotation Drive Assembly Parts List
Item Part No. Description
1 SHCS #10-24 x 5/8 Long
2 Split Washer #10
3
1.007.4102
Drive Gear
4
1.006.8180
Gear Encoder Disk
5
1.007.4105
Gear Clamp
6
1.007.4106
Rotation Motor Bracket
7
1.007.4107
Al. Round Spacer
8
1.007.3996
Gear Encoder
9 Split Washer #6
10 SHCS #6-32 x 1/2 Long
11
1.005.8631
Stepper Motor
12
1.007.5725
Thomson Micron #NTR23-025
13 Split Washer #10
14 SHCS #10-24 x 1/2 Long
15 SHCS #10-24 x 3/4 Long
