2-9
Illustrated Parts Breakdown
032-0358-EN Rev B
X-Ray Source Assembly Parts List
Item
Part No.
Description
1
0.830.4966
Rear X-Ray Source Cover Assembly
2 BHCS #8-32 x 1/2 Long
3 SHCS 1/4-20 x 1 Long
4 Split Washer 1/4
5
1.005.8633
Tube Head Assembly
6
1.005.8622
Cross Laser Assembly
7
0.830.0492
Cross Laser Mirror
8 BHCS #6-32 x 1/4 Long
9 Split Washer #10
10 SHCS #10-24 x 3/8 Long
11
1.010.9900
Beam Limiter
12
1.013.0493
Patient Align Panel
13
0.830.4965
Front X-Ray Source Cover Assembly
14
1.006.5158
Beam Limiter Panel
15
1.006.3236
Beam Limiter Control PCB
16
1.007.4110
#6-32 x 1/2 Long Standoff McMaster #91
17
1.007.6278
Beam Limiter Board Shield
18 Split Washer #6
19 SHCS #6-32 x 1/4 Long
To Next Page
