2-1
032-0358-EN Rev B
Chapter
2
Illustrated Parts Breakdown
This chapter provides replacement part numbers. Ensure power is removed before servicing the scanner.
WARNING
High voltage is present in the scanner. Remove power from scanner before removing covers or
cables. To avoid personal injury from electrical shock, do not operate the system with any covers
open or cables removed.
To ensure power to the scanner is locked out from the main supply:
1. At rear of scanner, turn circuit breaker off.
2. Remove the overhead cord bracket.
3. Unplug the scanner line cord.
4. Re-install overhead cord bracket so that line cord cannot be
plugged in.
The following assemblies are illustrated.
• System Assemblies (page 2-2)
• Overhead Assembly (page 2-4)
• Rotation Drive Assembly (page 2-6)
• X-Ray Source Assembly (page 2-8)
• Flip Receptor Panel Assembly (page 2-10)
• Chair Assembly (page 2-12)
• Upper Chair Assembly (page 2-14)
1
2
3
