2-11
Illustrated Parts Breakdown
032-0358-EN Rev B
Flip Receptor Panel Assembly Parts List
Item Part No. Description
1 1.009.9646 Cover, Receptor Panel
2 1.009.9456 2520DX Receptor Panel
3 0.830.0627 Mounting Plate, Receptor 2520D
4 Flat Soc. Hd. M5
5 1.011.1955 Rear Receptor Cover Assy
6 1.007.4114 Stop Screw
7 1.007.4001 Drive Screw Assembly
8 SHCS M3 x 8mm Long
9 1.005.8630 Flip Stepper Motor
10 1.007.4003 Idler
11 1.007.4115 Cable Shield
12 Split Washer #10
13 SHCS #10-32 x 5/8 Long
14 1.007.4116 Belt McMaster #6484K511
15 0.830.0778 Flip Receptor Fan
16 1.007.4005 Belt Key
17 Flat Head Screw #8-32 x 3/8 Long
18 1.007.4007 Flip Receptor Limit Switch Assembly
19 SHCS #4-40 x 5/8 Long
20 SHCS #10-32 x 3 1/2 Long
