KEB COMBIVERT F4-F Applications Manual

© KEB Antriebstechnik, 1998
All rights reserved
Chapter Section Page
Date
21
KEB COMBIVERT F4-F
6
Name: Basis
11.12.98
Product DescriptionSummary
The following technical specifications refer to 2-/4-pole standard motors. In case of
different pole numbers the frequency inverter must be dimensioned for the rated
motor current. With regard to special or medium frequency motors, please contact
KEB.
Site altitude max. 2000 m. For altitudes of 1000 m or more above N.N. a power reduction
of 1 % per 100m must be taken into account.
1) The statement counts only for frequency inverters with internal braking transistor (see „2.1.4 Type Code“).
Inverter Size 07 12 13 14
15 16
Output nominal power
[kVA]
1,6 6,6 8,3 11 17 23
Max. rated motor power
[kW]
0,75 45,57,51115
Output nominal current
[A]
4 16,5 24334866
Max. short-time current
[A]
7,2 24,8 36,5 49,5 72 99
OC-tripping current
[A]
8,8 29,7 43 59 88 119
Nominal input current
[A]
8 4,4 33 18,1 26,5 36 53 73
Housing size DDEEGGHH
Rated operating frequency
[kHz]
16 8 16161616
Max.operating frequency
[kHz]
16 8 16161616
Power loss at nominal operating
[W]
65 210 220 280 430 550
Stall current at 8kHz
[A]
-- 16,5 19 - - -
Stall current at 16kHz
[A]
----8,6---
Max. heat sink temperatureT
OH
[°C]
85
73 90 90
90 90
Max. permissible mains fuse (inert)
[A]
20 10 35 25 35 50 80 80
Line cross section
[mm²]
2,5 1,5 6 4 6 10 25 25
Min. braking resistor
1)
[
Ω
]
56 21 16 13
5,6 5,6
Typ. braking resistor
1)
[
Ω
]
100 28 22 16
13,6 8,8
Max. braking current
[A]
7 19 29 29 70 70
Tightening torque for terminals
[Nm]
0,5 0,5 1,2
Mains voltage
[V]
305...500 +/-0 (400V Nominal voltage)
Phases 13133333
Mains frequency
[Hz]
50 / 60 +/- 2
Output voltage
[V]
3 x 0...U Mains
Output frequency
[Hz]
see control board
Shielded motor line length
[m]
30 30 100
Storage temperature
[°C]
-25...70 °C
Operating temperature
[°C]
-10...45 °C
Model / protective system
IP20
Relative humidity
max. 95% without condensation
Tested in accordance with...
EN 61800-3
Climatic category
3K3 in accordance with EN 50178
2.1.5 Validity of
Specifications
2.1.6 Unit Sizes 230V-Class
