4-14 Sweeps Model 6220/6221 Reference Manual
Return to Section 4 topics
Remote sweep operation
Procedures for programming and running a sweep for each of the three sweep types
are given on the following pages. Each of these procedures includes commands for a
typical sweep example. Table 4-3 summarizes parameters for each of these exam-
ples. See “SCPI commands — sweeps,” on page 4-18 for details on sweep com-
mands.
NOTE User setups cannot be saved or recalled while
sweep is armed or running. The *SAV and *RCL
commands will generate error +413 Not allowed
with mode armed.
Table 4-3
Sweep example parameters
Sweep type Parameters for sweep examples
Linear staircase sweep (page 4-15) Start current: 1mA
Stop current: 10mA
Step current: 1mA
Delay: 1s
Source range: best fixed
Compliance abort: off
Sweep count: 1
Bias current: 100μA
Compliance: 10V
Logarithmic staircase sweep (page 4-16) Start current: 1mA
Stop current: 10mA
# points: 5
Delay: 2s
Source range: best fixed
Compliance abort: off
Sweep count: 1
Bias current: 10μA
Compliance: 5V
Custom (list) sweep (page 4-17) # points: 5
Points: 3mA, 1mA, 4mA, 5mA, 2mA
Delay: 3s, 1s, 4s, 5s, 2s
Compliance: 3V, 1V, 4V, 5V, 2V
Source range: auto
Compliance abort: off
Sweep count: 1
Bias current: 50μA
