Model 6220/6221 Reference Manual Wave Functions (6221 Only) 7-3
Return to Section 7 topics
Wave function characteristics
Table 7-1 summarizes the basic characteristics of the four wave functions avail-
able in the Model 6221. More details on various aspects can be found in the fol-
lowing paragraphs.
Table 7-1
Wave function characteristics
Wave function Characteristics
Sine wave Frequency: 1mHz to 100kHz (page 7-5)
Amplitude: 1pA to 105mA peak (page 7-5)
Range: 2nA to 100mA (page 7-5)
Offset: 0 to ±105mA (page 7-6)
Phase marker: 0° to 360° (page 7-9)
Duration: 100ns to 999999.999s (page 7-10)
Square wave Frequency: 1mHz to 100kHz (page 7-5)
Amplitude: 1pA to 105mA peak (page 7-5)
Range: 2nA to 100mA (page 7-5)
Offset: 0 to ±105mA (page 7-6)
Duty cycle: 0 to 100% (page 7-7)
Phase marker: 0° to 360° (page 7-9)
Duration: 100ns to 999999.999s (page 7-10)
Ramp wave Frequency: 1mHz to 100kHz (page 7-5)
Amplitude: 1pA to 105mA peak (page 7-5)
Range: 2nA to 100mA (page 7-5)
Offset: 0 to ±105mA (page 7-6)
Duty cycle: 0 to 100% (page 7-7)
Phase marker: 0° to 360° (page 7-9)
Duration: 100ns to 999999.999s (page 7-10)
Arbitrary wave Frequency: 1mHz to 100kHz (page 7-5)
Amplitude: 1pA to 105mA peak (page 7-5)
Range: 2nA to 100mA (page 7-5)
Offset: 0 to ±105mA (page 7-6)
Number of points: 2 to 65,535
Phase marker: 0° to 360° (page 7-9)
Duration: 100ns to 999999.999s (page 7-10)
