Model 6220/6221 Reference Manual Getting Started 1-25
Return to Section 1 topics
To restore any setup
1. Press SETUP to open the RESTORE SETUP menu:
2. Select USER, PRESET, or *RST:
• USER – Enter the desired value (0 to 4) and press ENTER.
• PRESET – Press ENTER to return to the PRESET defaults.
• *RST – Press ENTER to return to *RST defaults.
To select power-on setup
1. Press the SAVE key to open the SAVED SETUP MENU.
2. Select the POWER ON menu item.
3. Select BENCH, GPIB, or USER SETUP NUMBER:
• PRESET – Press ENTER to select the PRESET defaults.
• *RST – Press ENTER to select the *RST defaults.
• USER SETUP NUMBER – Key in the desired user setup number and
then press ENTER.
Remote operation setups
Saving and restoring user setups
The *SAV and *RCL commands are used to save and recall user setups:
Restoring PRESet or *RST default setups
The SYSTem:PRESet command returns Model 622x to the PRESET defaults and
the *RST command returns it to the *RST defaults.
*SAV <NRf>
*RCL <NRf>
‘
‘
‘
Save present setup in memory.
Recall saved user setup from memory.
<NRf> = 0, 1, 2, 3, or 4
NOTE User setups cannot be saved or recalled while Wave,
Sweep, Delta, Pulse Delta or Differential Conductance is
armed or running. The *SAV and *RCL commands will gen-
erate error +413 (Not allowed with mode armed).
A custom (list) sweep cannot be saved as a user setup.
Attempting to do so will generate error +528 Cannot save
CUSTOM sweep setup.
Source preset values are not aved aspart of a user setup.
SYSTem:PRESet ‘ Restore PRESET default setup.
*RST ‘ Restore *RST default setup.
