17-16 Calibration Model 6220/6221 Reference Manual
Return to Section 17 topics
Table 17-4
Remote current calibration summary
Range Currents Commands*
100mA
100mA
0mA
-100mA
OUTP ON
SOUR:CURR:RANG 0.1
SOUR:CURR 0.1
CAL:PROT:SOUR <+FS_DMM_Reading>
SOUR:CURR 0
CAL:PROT:SOUR <0_DMM_Reading>
SOUR:CURR -0.1
CAL:PROT:SOUR <-FS_DMM_Reading>
20mA
20mA
0mA
-20mA
SOUR:CURR:RANG 2e-2
SOUR:CURR 2e-2
CAL:PROT:SOUR <+FS_DMM_Reading>
SOUR:CURR 0
CAL:PROT:SOUR <0_DMM_Reading>
SOUR:CURR -2e-2
CAL:PROT:SOUR <-FS_DMM_Reading>
2mA
2mA
0mA
-2mA
SOUR:CURR:RANG 2e-3
SOUR:CURR 2e-3
CAL:PROT:SOUR <+FS_DMM_Reading>
SOUR:CURR 0
CAL:PROT:SOUR <0_DMM_Reading>
SOUR:CURR -2e-3
CAL:PROT:SOUR <-FS_DMM_Reading>
200μA
200μA
0μA
-200μA
SOUR:CURR:RANG 2e-4
SOUR:CURR 2e-4
CAL:PROT:SOUR <+FS_DMM_Reading>
SOUR:CURR 0
CAL:PROT:SOUR <0_DMM_Reading>
SOUR:CURR -2e-4
CAL:PROT:SOUR <-FS_DMM_Reading>
20μA
20μA
0μA
-20μA
SOUR:CURR:RANG 2e-5
SOUR:CURR 2e-5
CAL:PROT:SOUR <+FS_DMM_Reading>
SOUR:CURR 0
CAL:PROT:SOUR <0_DMM_Reading>
SOUR:CURR -2e-5
CAL:PROT:SOUR <-FS_DMM_Reading>
* Use DMM (Figure 17-1) for 100mA-200nA ranges.
* Use picoammeter (Figure 17-2) for 20nA and 2nA ranges.
