Remote wave function operation

Procedures for programming and generating waveforms for each of the four wave-

form types are given on the following pages. Each of these procedures includes

commands for a typical wave function example. Table 7-3 summarizes parameters

for each of these examples. See “SCPI commands — wave functions,” on

page 7-27 for details on wave function commands.

NOTE User setups cannot be saved or recalled while

Wave is armed or running. The *SAV and *RCL

commands will generate error +413 Not al-

lowed with mode armed.

Table 7-3

Waveform example parameters

Waveform Parameters for waveform examples

Sine wave (page 7-22) Frequency: 1kHz

Amplitude: 10mA

Offset: 1mA

Phase marker: off

Duration: 5s

Square wave (page 7-23) Frequency: 10kHz

Amplitude: 1mA

Offset: 0

Duty cycle: 50%

Phase marker: 180°, line 1

Duration: 10s

Ramp wave (page 7-24) Frequency: 50kHz

Amplitude: 5mA

Offset: 0

Duty cycle: 25%

Phase marker: 90°, line 1

Duration: 15s

Arbitrary wave (page 7-25) Arbitrary points: -0.5, -0.25, 0, 0.3, 0.4

Range: best fixed

Frequency: 100kHz

Amplitude: 25mA

Offset: 0

Phase marker: Off

Duration: 20s
