10-4 Remote Operations Model 6220/6221 Reference Manual
Return to Section 10 topics
Configuring the GPIB interface
1. Press the COMM key, select GPIB, and press ENTER.
2. If you are changing to the GPIB from a different interface, the Model 622x
will perform a power-on reset, and you must re-enter the COMM menu.
3. Set the primary ADDRESS to the desired value (0–30; default: 12), and
then press ENTER.
4. Choose SELECT LANGUAGE, press ENTER, and then chose either the
SCPI (SCPI 1996.0 which includes 488.2) or KI-220 (DDC) language.
Press ENTER to complete your selection.
See “GPIB interface reference,” on page 10-19 for full details on using the GPIB
interface.
Table 10-1
Communications menu
Menu item Description
GPIB
ADDRESS
SELECT LANGUAGE
Select/configure GPIB interface.
Set primary address (0-30), default 12.
Select SCPI or KI-220 language.
RS-232
BAUD
TERMINATOR
FLOW-CTRL
Select/configure RS-232 interface.
Set baud rate (300, 600, 1200, 2400, 4800, 9600, 19.2K,
38.4K, 57.6K, or 115.2K).
Select terminator (<CR>, <CR+LF>, <LF>, or <LF+CR>).
Select flow control (NONE or XON-XOFF).
ETHERNET
MAC
IP
GATEWAY
SUBNET
DHCP
Select/configure Model 6221 Ethernet interface.
1
Display MAC address.
2
Typical:123.456.789.012.345.678
Set/view IP address.
3
Format: IP: 000.000.000.000
Set/view Ethernet gateway.
3
Format: GW: 000.000.000.000
Set/view subnet mask.
3
Format: SN: 000.000.000.000
Select DHCP control (ON or OFF).
4
PA SS WOR D
NO
YES
Select whether to clear communications password.
5
Do not clear password.
Clear password.
1. The Ethernet interface is not available on the Model 6220.
2. The MAC address is displayed only and cannot be changed by the user. Typical decimal notation address
shown.
3. Formats shown only for example. Actual numeric values depend on settings.
4. It is not necessary to manually set the IP address, Ethernet gateway, and subnet mask if DHCP control is ON,
and the LAN has a DHCP server. See “Ethernet settings,” on page 10-33.
5. See “Password,” on page 10-6 and Table 10-2 for password details.
