8-10 Triggering Model 6220/6221 Reference Manual
Return to Section 8 topics
SCPI commands — triggering
Triggering commands are listed in Table 8-2 . Additional information for each com-
mand is provided in notes that follow the tables.
Table 8-2
Trigger commands
Command* Description Default
INITiate Initiate one trigger cycle.
1
OFF
ABORt Reset trigger system.
2
Arm layer commands:
ARM:SOURce <name> Select event detector control source.
3
<name> = IMMediate, TIMer, BUS,
TLINk, NSTest, PSTest, NSTest,
or MANual.
IMM
ARM:SIGNal Bypass ARM control source.
4
ARM:TIMer <n> Set timer interval (0 to 99999.99 sec).
1 msec resolution.
5
0.1
ARM:DIRection <name> Control ARM source bypass.
6
<name> = SOURce or ACCeptor
ACC
ARM:ILINe <NRf> Set ARM layer input signal line (1-6).
7
1
ARM:OLINe <NRf> Set ARM layer output signal line (1-6).
8
2
ARM:OUTPut <name> Enable/disable ARM layer output trigger.
9
<name> = TENTer, TEXit, or NONE
NONE
Trigger layer commands:
TRIGger:SOURce <name> Select event detector control source.
10
<name> = IMMediate or TLINk.
IMM
TRIGger:SIGNal Bypass TRIG control layer.
11
TRIGger:DIRection <name> Control TRIG source bypass.
12
<name> = SOURce or ACCeptor
ACC
TRIGger:ILINe <NRf> Set TRIG layer input signal line (1-6).
13
1
TRIGger:OLINe <NRf> Set TRIG layer output signal line (1-6).
14
2
TRIGger:OUTPut <name> Select TRIG layer output trigger.
15
<name> = SOURce[1], DELay, or NONE
NONE
* Arm layer commands control entire sweep. Trigger layer commands control individual sweep steps.
