14-18 SCPI Reference Tables Model 6220/6221 Reference Manual
Return to Section 14 topics
:ILINe? Query TRIG input signal line.
:OLINe <NRf> Set TRIG output signal line: 1 to 6. 2
:OLINe? Query TRIG output signal line.
:OUTPut <name> Enable/disable TRIG output trigger:
SOURce[1], DELay, or NONE.
NONE
:OUTPut? Query TRIG output trigger.
Table 14-11
Units command summary
Command Description Default Sec SCPI
UNIT Commands to set reading units for Delta, Pulse Delta,
and Differential Conductance:
5
[:VOLT] Volts readings are sent from 2182/2182A to 622x.
[:DC] <name> Specify reading units*: V, OHMS, W, or SIEMens. V
[:DC]? Query reading units.
:POWer Power reading type for Pulse Delta (6221):
[:TYPE] <name> Set power units reading type: PEAK or AVERage. AVER
[:TYPE]? Query power units reading type.
* The <name> parameter for Siemens can be sent as S, SIEM or SIEMENS.
Table 14-10 (cont.)
Trigger command summary
Command* Description Default Sec SCPI
* Arm layer commands control entire sweep. Trigger Layer commands control individual sweep steps.
