1-24 Getting Started Model 6220/6221 Reference Manual
Return to Section 1 topics
Error and status messages
Error and status messages are displayed momentarily. During operation and
programming, you will encounter a number of front panel messages. Typical
messages are either of status or error variety, as listed in Appendix B.
Messages, both status and error, are held in queues. For information on retrieving
messages from queues, see Section 11.
Default settings
The Model 622x can be restored to one of seven setup configurations: five user-
saved setups, PRESET (bench defaults), and *RST (bus defaults). As shipped
from the factory, the Model 622x powers up to the PRESET settings. PRESET set-
tings provide a general purpose setup for front panel operation, while the *RST
settings do the same for remote operation.
Default settings for front panel operation are listed in Table 1-1. For front panel
operation, PRESET and *RST defaults are the same. For remote operations, the
defaults are included in the SCPI table (see Section 14).
The instrument will power up to the default setup that was saved as the power-on
setup.
Front panel setups
To save a user setup
1. Configure the Model 622x for the desired sourcing application.
2. Press the SAVE key to open the SAVED SETUP MENU.
3. Select the SAVE menu item.
4. Enter the desired memory location (0 through 4) and press ENTER.
NOTE At the factory, the PRESET default setup is saved into the
five user-saved setups.
NOTE User setups cannot be saved or recalled while Wave,
Sweep, Delta, Pulse Delta, or Differential Conductance is
armed or running. Attempting to do so will generate error
+413 Not allowed with mode armed.
A custom sweep cannot be saved as a user setup. Attempting
to do so will generate error +528 Cannot save CUSTOM sweep
setup.
Source preset values are not saved as part of a user setup.
