Keithley 6220 User Manual

2-6 Output Connections Model 6220/6221 Reference Manual
Return to Section 2 topics
Figure 2-4
Output configurations – triax inner shield connected to Output Low
Figure 2-5
Output configurations – triax inner shield connected to Cable Guard
1) Boot color for alligator
clip if using supplied
triax cable.
2) Frequency Variable
Resistor (FVR). See
Figure 2-1.
A) Triax Output Low setting: Earth Ground B) Triax Output Low setting: Floating
OUTPUT
FVR
Chassis
Earth
Ground
105V
Max
250V
Max
Output High
(red)
Output Low
(black)
Earth Ground
(green)
622x
OUTPUT
FVR
Chassis
Earth
Ground
105V
Max
Output High
(red)
Output Low
(black)
Earth Ground
(green)
622x
1
1
1
1
1
1
2
2
OUTPUT
FVR
Chassis
Earth
Ground
OUTPUT
FVR
250Vpk
Max
105Vpk
Max
LO
105Vpk
Max
105Vpk
Max
105Vpk
Max
Chassis
Earth
Ground
Output High
(red)
Cable Guard
(black)
62xx
62xx
Output High
(red)
Cable Guard
(black)
Output Low
Earth Ground
(green)
Output Low
(Earth Ground)
(green)
1
1
1
1
1
1
A) Triax Output Low setting: Earth Ground B) Triax Output Low setting: Floating
1) Boot color for alligator
clip if using supplied
triax cable.
2) Frequency Variable
Resistor (FVR). See
Figure 2-1.
2
2
