Model 6220/6221 Reference Manual Wave Functions (6221 Only) 7-15
Return to Section 7 topics
Table 7-2
Wave function configuration menu
Menu selection Description
TYPE
SINE
SQUARE
RAMP
ARBx
Select waveform type:
Select sine wave.
Select square wave.
Select ramp wave.
Select user-defined arbitrary wave. *
Where: x = 0 to 4.
OFFS Enter DC offset (0 to ±105mA).
AMPL-UNIT Select amplitude units (PEAK or RMS).
(Front panel only.)
DUTY-CYCLE Enter duty cycle (0 to 100%; square and ramp only).
PH-MKR
STATE
OUTPUT-POINT
OUTPUT-LINE
Select phase marker and line:
Turn phase marker ON or OFF.
0 to 360°
Set trigger output line (OFF, #1 to #6).
DURATION
INFINITE
SET-TIME
SET-CYCLES
Set duration of waveform:
Continuous waveform.
Set duration in time (0.001s to 999999.999s).
Set duration in cycles (0.001 to 99999999900).
RANGING
BEST-FIXED
FIXED
Select ranging for selected wave function:
Select best range based on wave amplitude.
Stay on fixed range when waveform is armed.
MORE Expand to show additional menu items:
TRIG-MODE
MAN/BUS
NONE
TLNK-#1
#2
#3
#4
#5
#6
Configure low jitter external waveform triggering:*
Disable external trigger mode (default).
Enables external trigger mode with no line selected.
Enables external trigger on trigger link line 1.
Enables external trigger on trigger link line 2.
Enables external trigger on trigger link line 3.
Enables external trigger on trigger link line 4.
Enables external trigger on trigger link line 5.
Enables external trigger on trigger link line 6.
RE-TRIG
IGNORE-TRIG
RESTART-IMMEDIATELY
Configure response to external retriggering:
Ignore subsequent triggers while outputting a wave.
Restart waveform immediately upon each trigger.
INACTIVE-VAL Set output value before and after triggered waveforms.
* Arbitrary waveforms can only be defined via remote. Waveform triggering with firmware A03 and later.
