Model 6220/6221 Reference Manual KI-220 Language 15-3
Return to Section 15 topics
Notes:
The following notes explain the operational differences between the Models 622x
and Model 220. Some notes provide additional information for the commands
listed in Table 15-1.
Range R0
R1
R2
R3
R4
R5
R6
R7
R8
R9
Auto
1nA
10nA
100nA
1µA
10µA
100µA
1mA
10mA
100mA
Trigger T0
T1
T2
T3
T4
T5
T6
T7
Start on Talk
Stop on Talk
Start on GET
Stop on GET
Start on X
Stop on X
Start on External Trigger
Stop on External Trigger
Terminator Y0
Y1
Y2
Y3
Y4
CR LF
LF CR
CR
LF
None
Note 11
Inputs I
V
W
B
L
Current Source
Voltage Limit
Dwell Time
Buffer Address
Memory Location
Note 8
Note 5
Notes 7, 10
I/O Port O (0-15) Set Output Control Bits Note 1
Status U0
U1
Send Status Word
Send I/O Port Status
Digital Self-Test J0 Not Supported
Execute X Execute other DDCs
Table 15-1 (cont.)
DDC emulation commands
