KERN PES 620-3M

91 TPES-B_TPEJ-B-BA-e-2319
Set baud rate:
Set parity:
Parity can only be set if the interface is set to 2 or 3 (see chapter 19.9.1).
Set the data length:
The data length can only be set if the interface has been set to 3 (see
chapter 19.9.1).
Set stop bit:
 Navigate to <62.bL.> in the menu and
select the desired setting.
1
1200 bps
2
2400 bps
3
4800 bps
4
9600 bps
5
19200 bps
 Navigate to <63.PA.> in the menu and
select the desired setting
0
Empty
1
Odd
2
Even
 In the menu navigate to <64.dL.> and
select the desired setting
7
7 Bit
8
8 Bit
 In the menu navigate to <65.St.> and
select the desired setting
1
1 Bit
2
2 Bit
