Keysight Technologies E8257D User Manual

110 E8257D/67D, E8663D PSG Signal Generators Service Guide
Troubleshooting
Troubleshooting Unlevels
>3.2 GHz to 20 GHz +13 +20 +11 +18 +9 +18 +7 +16 +5 +14 +3 +13
>20 GHz to 30 GHz +9 +14 +7 +12 +5 +11 +3 +9
>30 GHz to 40 GHz +9 +14 +7 +12
>30 GHz to 65 GHz +5 +11 +3 +9
>65 GHz to 67 GHz +5 +10 +3 +8
>67 GHz to 70 GHz +5 +8 +3 +6
a. always check data sheet for updates to specifications
b. with filters switched out
Table 1-15 E8257D Maximum Leveled Power (dBm)
a
Frequency 20 GHz Models 40 GHz Models 50 & 67 GHz Models
Std. 1EA/
1EU
1E1 1E1+
1EA/
1EU
Std. 1EA/
1EU
1E1 1E1+
1EA/
1EU
Std. 1EA/
1EU
1E1 1E1+
1EA/
1EU
Table 1-16 E8267D Maximum Leveled Power (dBm)
a
Frequency 20 GHz Models 32 & 44 GHz Models
250 kHz to 3.2 GHz +13 +12
250 kHz to 3.2 GHz w/UNW +9 +8
250 kHz to 3.2 GHz w/1EH
b
+10 +9
250 kHz to 3.2 GHz w/UNW + 1EH
b
+7 +6
>3.2 GHz to 20 GHz +18 +14
>20 GHz to 31.8 GHz +14
>31.8 GHz to 40 GHz +12
>40 GHz to 44 GHz +10
a. Always check data sheet for updates to specifications
b. With filters switched out
Table 1-17 E8663D Maximum Leveled Power (dBm)
a
Frequency All Models
Std. 1EU 1E1 1E1+1EU
100 kHz to 3.2 GHz +15 +23 +15 +23
100 kHz to 3.2 GHz w/UNX +13 +23 +15 +23
100 kHz to 3.2 GHz w/1EH
b
+13 +23 +15 +23
