E8257D/67D, E8663D PSG Signal Generators Service Guide 215
Replaceable Parts
Cables
W95
(Options 550 & 567)
A10J202 A36J6 8120-6990
W96
(Options 550 & 567)
A11J206 A36J5 8121-6990
W97
(E8267D)
A35J8 A37J8 8121-0627
W98
(E8267D)
A30J1 A37J2 E8251-20218
W99
(E8267D)
(Options 532 & 544)
A37J7 (backside) A26J34 8121-1241
W100
(E8267D)
(Options 532, 540, & 544)
A27J2 (RF out) A37J5 (LO in) E8251-20216
W101
(E8267D)
(Options 532 & 544)
A28 A39 Directional Sweep Coupler (input) E8251-20331
W102
(E8267D)
(Options 532 & 544)
A37J4 (RF out) Semi-Rigid Cable,
A24 50 GHz Highband Coupler (input)
E8251-20310
W103
(E8267D)
(Options 532 & 544)
A30J2 A37J3 E8251-20219
W104
(E8267D)
A27J1 A35J3 E8251-20215
W105
(E8267D)
A35J4 A29J3 E8251-20077
W106
(Options 550 & 567)
A36J1 A30J4 E8251-20313
W107
(Options 550 & 567)
A36J2 A30J2 E8251-20314
W108
(Options 550 & 567)
A36J4 A30J6 8120-6990
W109
(Options 550 & 567)
A10J201 A36J3 8120-6990
W110
(Options 532 & 544)
A10J202 A37J6 8121-6990
Table 2-4 (Continued)
Reference Designator Input Output Part Number
