214 E8257D/67D, E8663D PSG Signal Generators Service Guide
Replaceable Parts
Cables
W82
(Options 532 & 544)
(Option 1EM)
Semi-Rigid Cable, A24 50 GHz
Highband Coupler
2.4 mm RF Output
connector
(models without Option 1E1)
E8251-20309
W83
(Option 1EM)
A27J2 A24 Highband Coupler input E8251-20070
W84
(Option 1EM)
Semi-Rigid Cable, A24 40 GHz
Highband Coupler output
AT1 115 dB Mechanical Attenuator
(input)
E8251-20071
W85
(Option 1EM)
Semi-Rigid Cable, AT1 115 dB
Mechanical Attenuator
2.4mm RF Output connector
(RF OUT)
E8251-20585
W86
(Options
503/509/513/520/521)
Semi-Rigid Cable, AT1 output 3.5 mm or Type-N RF Output
connector
E8251-20581
W87
(Option 540)
(Option 1EM)
Semi-Rigid, A24 40 GHz Highband
Coupler in
RF Output adapter
(models without Option 1E1)
E8251-20586
W88
(Options
503/509/513/520/521)
(Option 1EM)
Semi-Rigid, A24 20 GHz Highband
Coupler (in)
RF Output adapter
(models without Option 1E1)
E8251-20096
W89
(Options 550 & 567)
for instruments with serial
prefix < US/MY5644
Semi-Rigid Cable, A24 20 GHz
Highband Coupler (out)
2.4mm RF Output connector
(models without Option 1E1)
E8251-20346
b
for instruments with serial
prefix ≥ US/MY5644
Semi-Rigid Cable, A24 20 GHz
Highband Coupler (out)
2.4mm RF Output connector
(models without Option 1E1)
E8251-20593
W90
(E8267D)
A14J21 A17P1 8121-0690
W91
(Options 550 & 567)
(Option 1EM)
Semi-Rigid Cable,
A24 67 GHz Highband Coupler
(output)
1.85 mm RF Output connector
(models without Option 1E1)
E8251-20318
W92
(Option 550 & 567)
Semi-Rigid Cable,
AT1 115 dB Mechanical Attenuator
(output)
1.85 mm RF Output connector E8251-20321
W93
(Options 532 & 544)
(Option 1EM)
Semi-Rigid Cable,
A24 50 GHz Highband Coupler
(output)
AT1 115 dB Mechanical
Attenuator (input)
E8251-20312
W94
(Options 550 & 567)
(Option 1EM)
Semi-Rigid Cable, AT1 90 dB
Mechanical Attenuator (output)
1.85 mm RF Output connector E8251-20322
Table 2-4 (Continued)
Reference Designator Input Output Part Number
