E8257D/67D, E8663D PSG Signal Generators Service Guide 217
Replaceable Parts
Cables
W123
e
(E8267D with Option 016)
A13J15 Rear Panel (Wideband Q In (+)) 8121-1667
W124
e
(E8267D with Option 016)
A13J16 Rear Panel (Wideband -Q In (-)) 8121-1667
W125
e
(E8267D with Option 016)
A13J19 Rear Panel (Wideband I In (+)) 8121-1667
W126
e
(E8267D with Option 016)
A13J20 Rear Panel (Wideband -I In (-)) 8121-1667
W127
f
(E8267D with Option 016)
A13J17 A35J109 8121-1616
W128
f
(E8267D with Option 016)
A13J18 A35J107 8121-1616
W129
f
(E8267D with Option 016)
A13J21 A35J108 8121-1616
W130
f
(E8267D with Option 016)
A13J22 A35J106 8121-1616
W131
g
(E8267D with Option 016)
A13J9 A31J1053 8121-1618
W132
g
(E8267D with Option 016)
A13J10 A31J1052 8121-1618
W133
(Options
503/509/513/520/521)
Semi-Rigid, A24 20 GHz Highband
Coupler (output)
RF Output adapter
(models without Option 1E1)
E8251-20584
W134
(E8267D)
A30J1 A35 I/Q Mod E8251-20019
W135 Cable Assembly, A42J9 A31P242 E8251-60850
W136
h
A18P2 A40 Compact Flash PCA 8182-1807
W137 Semi-Rigid, A31 Motherboard
(Reference)
W121 E8251-20595
W138 Semi-Rigid, A43 Lowband Amp Filter W140 E8251-20489
W139 A43 Lowband Amp Filter A11J204 8120-6990
W140 Semi-Rigid, W138 A31 Motherboard (Output) E8251-20488
Table 2-4 (Continued)
Reference Designator Input Output Part Number
