Specifications Appendix A
Keysight N6700 User’s Guide 101
Supplemental Characteristics (continued)
Operating environment
Temperature range
Relative humidity
Altitude
Storage temperature
Indoor use, installation category II (for AC input),
pollution degree 2
0°C to 55°C (output current is derated 1% per °C above 40°C
ambient temperature)
Up to 95%
Up to 2000 meters
-30°C to 70°C
Acoustic Noise Declaration:
This statement is provided to
comply with the requirements of the
German Sound Emission Directive,
from 18 January 1991.
Sound Pressure Lp <70 dB(A), At Operator Position,
Normal Operation, According to EN 27779 (Type Test).
Schalldruckpegel Lp <70 dB(A), Am Arbeitsplatz,
Normaler Betrieb, Nach EN 27779 (Typprüfung).
Output Terminal Isolation:
Maximum Rating
No output terminal may be more than 240 VDC from any other
terminal or chassis ground.
When using the AUX measurement input terminals on Models
N6781A and N6785A, no output or input terminal may be more
than ±60 VDC from any other terminal or chassis ground.
Input Ratings
Power Consumption
Power Factor
NOTE 1
Fuse
~ 100 VAC – 240 VAC; 50/60/400Hz
1000 VA (N6700B)
1440 VA (N6701A)
1440 VA (N6702A @ < 180 VAC input)
2200 VA (N6702A @ > 180 VAC input)
0.99 @ nominal input and rated power
Internal fuse - not customer accessible.
AC mains circuits rated at 100-180 VAC
supply enough
current to power the N6702A mainframe when operated at its full
rated power. When connected to a 100-180 VAC mains, internal
circuits will limit the power available to modules to 600 W
maximum.
N6700B with 4 power modules
N6701A with 4 power modules
N6702A with 4 power modules
Single power module (typical)
12.73 kg / 28 lbs.
11.82 kg / 26 lbs.
14.09 kg / 31 lbs.
1.23 kg / 2.71 lbs
Refer to the outline diagrams on the following page.
1
Under full load at 400 Hz, power factor drops from 0.99 @ 120 VAC to as low as
0.76 @ 265 VAC. Power factor degrades further under no load conditions.
