4 Operating the Power System
62 Keysight N6700 User’s Guide
Programming the Output
Select a Channel View
Press the Meter key to toggle
between single-channel and
multiple-channel view.
To select single-channel view:
DISP:VIEW METER1
To set multiple-channel view:
Press the Channel key to select
an output channel.
Enter the selected channel(s) in
the command’s parameter list.
OUTP;STAT?
Press the Voltage key.
Enter a value and press Select.
To set output 1 to 5 V:
VOLT 5,(@1)
To set all outputs to 10 V:
For models with multiple ranges, you can select a lower range if you
need better output resolution.
Press the Voltage key.
Select a lower range and press
Select.
To select the lower range,
program a value that falls within
the range:
For Keysight Models N678xA SMU operating in current priority mode,
you can specify a Voltage limit., which limits the output voltage at the
specified value. In current priority mode, the output current remains at
its programmed setting as long as the output voltage is within the
positive or negative limit. Check Tracking
t
let the negative voltage limit
track the positive voltage limit setting.
Press the Voltage key.
Specify a + Voltage limit and or a
− Voltage limit and press Select.
Check the Tracking box if you
want the − limit to track the +
limit.
To select the voltage limit:
VOLT:LIM 5,(@1)
To select the negative voltage
limit:
VOLT:LIM:NEG 3,(@1)
To enable voltage limit tracking:
